Manipulator3D — 3-DOF Two-Link Robot Arm (Analytic IK + Pick&Place)

A Java simulation and visualization project for a 3-DOF, two-link manipulator with a fixed base in 3D space. The arm executes a simple pick-and-place loop using an analytic inverse kinematics solver and a linear end-effector trajectory.

• Joint 0 (base): revolute yaw about the +Z axis at the origin (0,0,0).
• Joints 1–2 (links): revolute pitch angles defining motion in the arm’s vertical plane (relative to the X–Y plane).
• IK: reduces the 3D target to a 2D planar problem in (r,z), solves with the law of cosines, and supports elbow-up / elbow-down branches.
• Visualization: rendered with raylib via Jaylib, including an overlay panel and a suction-tool “ball” pick-and-place animation.

Build system: Gradle • Rendering: raylib (Jaylib) • Language: Java 17 • IK: Closed-form

---

Table of Contents

• About this repository
• Repository structure
• Robotics: kinematics, dynamics, and inverse kinematics
• Building the project
• Running the simulator
• Repository file guide (full explanation)
• Simulation video
• Troubleshooting

---

About this repository

This project simulates a 3-DOF, two-link manipulator mounted on a fixed base at the origin:

• The base joint rotates around the Z axis (yaw).
• The two link joints rotate as pitch angles (relative to the X–Y plane) in the arm’s vertical plane.
• The end-effector (EE) tracks a sequence of target points with analytic inverse kinematics.
• A small “ball” is used to visualize a pick-and-place loop:
  1. HOME → START
  2. PICK at START (attach ball)
  3. START → GOAL
  4. PLACE at GOAL (detach ball)
  5. GOAL → HOME
  6. wait briefly and repeat

User inputs (via console prompt):

• START position (x y z) and GOAL position (x y z)
• Constraint enforced by IK: z must be ≥ 0
• Reachability enforced by IK: |p| must be within the arm’s reachable shell.

---

Repository structure

Manipulator3D_Java/
  build.gradle
  settings.gradle
  README.md
  resources/
    fonts/
      Inter-Regular.ttf   (optional)
  src/
    main/
      java/
        manipulator3d/
          Main.java
          robot/
            Vec3f.java
            LinkParams.java
            JointAngles.java
            FKResult.java
            IKResult.java
            RobotArm.java
          sim/
            LinearTrajectory.java
          ui/
            Overlay.java
          render/
            DrawUtils.java

---

Robotics: kinematics, dynamics, and inverse kinematics

1) Coordinate frames and joint conventions

• World frame origin is at the center of the base revolute joint: (0,0,0).
• Joint angles:
  • q0Yaw : rotation about +Z (sets the arm’s radial direction in the X–Y plane)
  • q1Pitch: shoulder elevation angle relative to the X–Y plane
  • q2Pitch: elbow pitch angle (relative bend in the same vertical plane)

We use the radial unit direction in the X–Y plane:

$$ \mathbf{u} = \begin{bmatrix} \cos(q_0)\\ \sin(q_0)\\ 0 \end{bmatrix}, \quad \mathbf{k} = \begin{bmatrix} 0\\ 0\\ 1 \end{bmatrix}. $$

2) Forward kinematics (FK)

Let link lengths be $L_1$ and $L_2$. Then:

• Elbow position:

$$ \mathbf{p}_1 = L_1\cos(q_1),\mathbf{u} + L_1\sin(q_1),\mathbf{k} $$

• End-effector position:

$$ \mathbf{p}_{ee} = \mathbf{p}_1 + L_2\cos(q_1+q_2),\mathbf{u} + L_2\sin(q_1+q_2),\mathbf{k} $$

This is implemented in:

• manipulator3d.robot.RobotArm#forwardKinematics(...)

3) Workspace (reachability) check

This manipulator is effectively a 2-link arm in a vertical plane, rotated by yaw. Therefore the reachable radius must satisfy:

$$ r_{\min} = |L_1 - L_2|,\quad r_{\max} = L_1 + L_2 $$

$$ |\mathbf{p}| \in [r_{\min}, r_{\max}] $$

The implementation enforces:

• target.z >= 0
• |p| within [minReach(), maxReach()]

4) Analytic inverse kinematics (IK): how it works here

Given target $\mathbf{p} = (x,y,z)$:

Step A — base yaw

$$ q_0 = \mathrm{atan2}(y, x) $$

Step B — reduce to planar IK in $(r,z)$

$$ r = \sqrt{x^2 + y^2} $$

Now solve a 2-link planar problem for the triangle formed by $L_1$, $L_2$, and $\sqrt{r^2+z^2}$.

Step C — elbow angle from law of cosines

$$ \cos(q_2) = \frac{r^2 + z^2 - L_1^2 - L_2^2}{2L_1L_2} $$

Clamp to $[-1,1]$ for numerical safety, then:

$$ q_2 = \pm \arccos(\cos(q_2)) $$

This sign is the elbow-up / elbow-down branch selection.

Step D — shoulder angle

Define:

$$ k_1 = L_1 + L_2\cos(q_2),\quad k_2 = L_2\sin(q_2) $$

Then:

$$ q_1 = \mathrm{atan2}(z, r) - \mathrm{atan2}(k_2, k_1) $$

This is implemented in:

• manipulator3d.robot.RobotArm#solveIK(...)

Practical note (this repo):

• The main program uses the default elbow branch (elbow-down) by passing elbowUp = false.

5) Dynamics (what is implemented vs. what is prepared)

This repository is primarily a kinematic + trajectory simulator:

• The EE follows a commanded Cartesian trajectory.
• IK converts EE targets into joint angles.
• FK is used for rendering joint/link positions.

However, the code also defines mass and inertia properties for each link (uniform rod approximations):

• About center of mass:

$$ I_{cm} = \frac{1}{12} mL^2 $$

• About the joint at one end:

$$ I_{joint} = \frac{1}{3} mL^2 $$

These are computed in:

• manipulator3d.robot.LinkParams#recomputeInertia()

Currently, those values are used for display/inspection (overlay panel) and as a foundation for extending the project to:

• forward dynamics (torques → accelerations),
• gravity and Coriolis terms,
• joint-space controllers (PD, computed torque, etc.).

---

Building the project

Dependencies

• Java 17+ (JDK)
• Gradle 7+ (Gradle 8+ recommended)
• raylib bindings are resolved automatically through Gradle via Jaylib

Build commands

From the project root:

gradle build

---

Running the simulator

Run command

From the project root:

gradle run

macOS note:

• Some macOS configurations require starting Java on the first thread. If you see a startup error, run with:

  gradle run --jvm-args="-XstartOnFirstThread"

Controls / interaction

• At startup, the console asks for:
  • START (x y z) and GOAL (x y z)
• Mouse wheel: zoom camera
• F11: toggle fullscreen
• Overlay includes a PAUSE/PLAY button and reachability feedback

---

Repository file guide (full explanation)

This section explains every important file in the repository and its role.

build.gradle

Key responsibilities:

• configures a Java 17 application
• fetches Jaylib from Maven Central
• sets the main entry point: manipulator3d.Main

---

src/main/java/manipulator3d/Main.java

This is the application entry point and runtime loop:

• prompts user for START and GOAL targets
• validates reachability using IK for:
  • fixed HOME EE point
  • START
  • GOAL
• defines a pick-and-place finite-state machine:
  • HOME → START → PICK → GOAL → PLACE → HOME → WAIT → LOOP
• generates a linear Cartesian trajectory between targets
• runs IK each frame to get joint angles for the current EE target
• calls FK for rendering joint/link positions
• renders:
  • robot geometry, thick axes, ball, suction tool
  • overlay panel (status, parameters, pause button)

---

src/main/java/manipulator3d/robot/RobotArm.java

Implements analytic FK and IK:

• IK:
  • rejects invalid targets (z < 0)
  • checks radius bounds (min/max reach)
  • computes yaw from atan2(y,x)
  • reduces to planar IK in (r,z)
  • solves elbow angle via law of cosines
  • solves shoulder angle via triangle decomposition
• FK:
  • constructs radial axis from yaw
  • builds elbow and EE positions from link lengths and pitch angles

---

src/main/java/manipulator3d/sim/LinearTrajectory.java

Implements linear interpolation in 3D:

• uses a normalized time parameter: $\alpha = \mathrm{clamp}(t/T, 0, 1)$
• outputs: $\mathbf{p}(\alpha) = \mathbf{a} + (\mathbf{b}-\mathbf{a})\alpha$

---

src/main/java/manipulator3d/ui/Overlay.java

Implements the overlay rendering:

• draws a semi-transparent panel
• displays:
  • link lengths, masses, inertias
  • workspace bounds
  • start/goal norms and coordinates
  • phase text and reachability warnings
• implements a clickable PAUSE/PLAY button

---

src/main/java/manipulator3d/render/DrawUtils.java

Implements rendering utilities using raylib primitives:

• text helpers:
  • drawTextBold()
  • drawTextSmall()
• “machined” robot look:
  • pedestal + base flange
  • joint housings (sphere + collar)
  • tapered link cylinders with end caps
  • suction tool at the EE

---

Simulation video

Below is a link to the simulation video on YouTube.

---

Troubleshooting

Jaylib can’t load natives / app fails to start

• Make sure you are running a supported desktop platform (Windows/macOS/Linux x86_64 or ARM64).
• If you are on macOS, try starting with:
  • -XstartOnFirstThread (see “Running the simulator”).

Start/Goal is “out of reach”

• Ensure:
  • z >= 0
  • |p| is within the workspace shell:
    • [|L1 - L2|, L1 + L2]
